Digi 001 Quick Start Guide34
S/PDIF Mirroring
Pro Tools LE uses S/PDIF mirroring to automatically “mirror” the audio that is sent to
outputs 1 and 2 on the S/PDIF RCA outputs. This is useful if you are monitoring a mix using
your audio outputs, and also recording the same source to an external S/PDIF device.
You can disable this S/PDIF mirroring. You might do this if you wanted to use the S/PDIF
outs to send a separate signal to an external digital effects unit, or if you wanted to send
only certain outputs to the digital device. If you disable S/PDIF mirroring you are able to
select the S/PDIF outputs separately, and route tracks or sends to them.
To enable or disable S/PDIF mirroring:
1 Choose Setups > Playback Engine.
2 Click Other Options.
3 Select or deselect the option “Enable S/PDIF Mirroring.”
Connecting Audio Sources
To connect an analog audio source:
■ Plug a microphone directly into Mic/Line Input 1 or 2 on the front of the Digi 001 I/O
Box. These inputs accept XLR connectors or 1/4" TRS connectors. If your microphone re-
quires phantom power, press the Phantom Power switch (labeled 48V).
▲ Although phantom power can be used safely with most microphones, ribbon mi-
crophones can be destroyed by it. You should always turn off phantom power,
and wait for the red light to go completely off, before connecting a ribbon micro-
phone.
■ Plug line-level sources (synths, outputs from your mixer, or microphones or guitars that
have been amplified by an outboard preamp) into the analog inputs on the back of the
Digi 001 I/O Box.
