Digikeijs DR5013 DIGIREVERSE User Manual

DR5013 DIGIREVERSE
P 2
www.digikeijs.com
® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
1 Index
1.0 General informaon 2
1.1 Index 2
1.2 Warranty and warranty condions 3
1.3 Legal informaon 3
2.0 Product overview 4
2.1 General product informaon 4
2.2 Technical Specicaons 4
2.3 Hardware Overview 5
3.0 Conguraon soware 6
3.1 Introducon 7
3.2 Download soware 7
3.3 Installing the conguraon soware 8
3.4 Connecng the DR5013 to the PC via USB 11
4.0 Programming 12
4.1 Overview Conguraon Soware 13
4.2 USB Features 14
4.3 Restoring the factory sengs 15
4.4 Updang the So- and Firmware 16
4.5 Firmware Versions 17
4.6 LocoNet® Features 18
4.7.0 Module Properes Part 1 19
4.7.1 Module Properes Part 2 20
4.8 Scripng with DR. Script 21
4.9 Properes of sensor tracks 22
4.10 Global Detector Features 23
5.0 Connecon examples 24
5.1 DR5013 Connecon for short-circuit detecon 25
5.2 DR5013 Connecon for short-circuit detecon with
LocoNet® 26
5.3 DR5013 Connecon with sensor track (S0,S1,S2,S3)
and LocoNet® 27
Please note this manual!
This manual currently contains only the basic information and will be extended
step by step. Suggestions, improvements, additions, comments or suggestions
are always welcome.
support@digikeijs.com
1 General Informaon
5.4 DR5013 Connecon with sensor tracks (S1,S2) with
LocoNet 28
5.5 DR5013 Connecon with sensor tracks (S1,S2) without
LocoNet® 29
5.6 External feedback connecon 30

Digikeijs DR5013 DIGIREVERSE Specifications

General

Brand	Digikeijs
Model	DR5013 DIGIREVERSE
Category	Control Unit
Language	English
