Digikeijs DR5013 DIGIREVERSE User Manual

DR5013 DIGIREVERSE
P 4
www.digikeijs.com
® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
2.0 Product overview
2.1 General product informaon
The DR5013 operates either with sensor tracks (short-circuit-free) or via "short-circuit detecon" to switch over the reversing loop. The polarity of the reversing
loop can also be changed via a switch command. The busy signal of the secons (T, S1, S2) can be done via LocoNet® or external output (for GND or CS feed-
back). A short-circuit message can be output via LocoNet or via the SHORT output of the module. An integrated Railcom® detector for address evaluaon and
POM reading is also included. An electronic high-speed MOSFET relay with 3 ampere load capacity for switching over ensures absolutely trouble-free and wear-
free reversing of polarity of the reversing loop. There is also a USB port for conguraon and rmware updates.
2.2 Technical specicaons
The terminals are designed for a cross-secon of 0.5mm².
Outputs Loading capacity of
the reversing loop
Inputs
DR5013 External Short-circuit Message
External feedback Reverse loop
(CS current sensor)
External feedback Reverse loop
(GND Ground switching)
3A Sensor track 1
Sensor track 2
Feedback unit Reverse loop occupied
Railcom® Detector reversing loop
