4.6.0 Module properes
1
2
3
4
5
6
7
8
9
10
11
1) Display Logging Window.
2) Select language.
3) Module address in LocoNet®.
4) Waing me aer the central unit has transmied power on before the track
voltage is acvated in the reversing loop.
5) Report feedback contacts aer switching on.
6) Waing me aer switching on before the contacts are reported.
7) Waing me unl the track voltage is switched o if a short circuit has been
detected.
8) Short circuit Send message via LocoNet® (track voltage is switched o glob-
ally).
None Do not send a short circuit message via LocoNet®.
CP_OFF Send short circuit message via LocoNet®.
OPC_PEER_XFER Send short circuit message via LocoNet®.
(Uhlenbrock® Specicaon)
Both Send both messages via LocoNet.
9) Switch the track voltage on again automacally aer a short circuit.
10) Waing me aer a short shot before the track voltage is reacvated.
11) Module Seng Export/Import
12) Accept current sengs
13) Cancel
14) Railcom® Use channel 2 for addional address recognion.
Up to 4 addresses can then be detected simultaneously by one detec-
tor.
15) Number of bits to be counted before a busy message is issued.*
16) Number of Railcom bits to be counted before direcon recognion
takes place.*
17) Waing me unl the direcon recognion is measured in a stable
way.*
18) Railcom® Detecon with Logging
*The lower the value, the faster the detecon is.
Noce! Not all funcons are supported by all decoders. Please refer to the
respecve decoder manual for details.
