1. Digitrax® specicaon for reporng 'short' locomove addresses.
Standard: Report 0x7D in high quality byte.
Alternave: Report 0x00 in high quality byte.
2. Block addresses are sent by Digitrax® only in even numbers. However,
the DR5013 can also send linear (even and odd) block addresses, ex-
tending the reporng range by 2048.
3. Report the speed of the locomoves to the control centre via Rail-
com®.
4. To prevent too many messages from being sent to the central unit
when the value changes quickly, a "Delta" value can be set here.
(*See example)
5. Report the signal quality of the Railcom® messages to the control cen-
tre.
The messages are reported by the decoder in %.
0% All commands have arrived (track or locomove clean).
100% of the commands have not arrived (track or locomove
dirty).
4.6.1 Module Properes
6
7
6. All QoS messages below this value are not reported to the central
unit.
7. A "Delta" value can be set here so that too many messages are not
sent to the central unit when the value changes quickly.
8. „"Report the "tank contents" of the locomoves to the central unit via
Railcom®.
*Example:
1. last measured value =10
newly measured value =6 Delta = 4
2. last measured value =3
newly measured value =9 Delta = 6
3. last measured value =12
newly measured value =1 Delta = 11
Parameter "Delta" = 6 The values 2. and 3. are reported, 1. is suppressed.
Noce! Not all funcons are supported by all decoders. Please refer to the
respecve decoder manual for details.
