DSE Model 5220 Automatic Mains Failure & Instrumentation System Operators Manual
5220 OPERATING MANUAL ISSUE 5.1 18-Jun-07 AM 35
9.2.8 PLUG “H” 4 WAY
PIN
No
DESCRIPTION
44 Oil Pressure sensing input. Connect to resistive type oil pressure sender. Refer to connection
diagram for details.
45 Coolant Temperature sensing input. Connect to resistive type coolant temperature sender. Refer
to connection diagram for details.
46 Fuel Level sensing input. Connect to resistive type fuel level sender. Refer to connection
diagram for details.
47 Sender Common connection. Return feed from sender units - refer to connection diagram for
details.
9.2.9 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE
If you require additional plugs from DSE, please contact our Sales department using the part numbers below.
5220 Terminal Connector Plug description DSE Part number
1-8 A BL08 8way 5.08mm spacing connector plug 007-125
9-19 B BL11 11way 5.08mm spacing connector plug 007-135
20-22 C BL03 3way 3.81mm spacing connector plug 007-409
23-26 D BL04 4way 3.81mm spacing connector plug 007-408
27-34 E BL08 8way 10.16mm spacing connector plug 007-410
35-38 F BL04 4way 10.16mm spacing connector plug 007-003
39-43 G BL05 5way 5.08mm spacing connector plug 007-329
44-47 H BL04 4way 5.08mm spacing connector plug 007-100
