DSE Model 5220 Automatic Mains Failure & Instrumentation System Operators Manual
5220 OPERATING MANUAL ISSUE 5.1 18-Jun-07 AM 45
15.1.3 2 PHASE, 3 WIRE ( 2 PHASE CENTRE TAP NEUTRAL)
The alternator is 2 phase star connected. The live phases are separated by 180°
L1
L2
N
F2A F2A
39 40 41 42
43
CT
common
CT
Earth
35
36 37 38
Not connected
F2A F2A
31
32 33 34
G M
LOAD
Mechanical interlock
Electrical interlock
Generator Mains (utility)
28273029
Generator
loading
relay
Mains
loading
relay
L1
L2
N
