DSE Model 5220 Automatic Mains Failure & Instrumentation System Operators Manual
40 057-012 5220 OPERATING MANUAL ISSUE 5.1 18/06/2007 AM
13 FACTORY DEFAULT CONFIGURATION
In the tables below, the icon
# indicates an item that can be adjusted from the module’s front panel editor.
Absence of the
# icon beside an item means that adjustment of this parameter is only possible using the 5200
series configuration software in conjunction with the P810 interface.
For further details on adjustment from the front panel editor, see the section entitled “Front panel configuration”
elsewhere within this manual.
Module settings Value
Base module 5220 automatic mains failure module
Miscellaneous settings Value
Alternator fitted Yes
Poles 4
Magnetic pickup fitted No
J1939 enabled No
AC System 3 phase, 4 wire
VT Ratio Disabled
Mains failure detection Enabled
Number of start attempts 3
Enable fast loading feature No
Immediate mains dropout Disabled
Input settings – Analogue | Oil pressure Value
Low oil pressure input type VDO 10 bar
Trip Return
Low oil pressure pre-alarm
#
1.17 Bar 17.0 PSI 1.24 Bar 18.0 PSI
Low oil pressure shutdown
#
1.03 Bar 14.9 PSI N/A
Input settings – Analogue | Coolant temp Value
High coolant temp input type VDO 120 degrees C
High coolant temp pre-alarm
#
115°C 239°F 110°C 230°F
High coolant temp shutdown
#
120°C 248°F N/A
Input settings – Analogue | Fuel level Value
Fuel level input type VDO Ohm
Range
Fuel pump control No
Low fuel level
#
10%
Input settings - Digital Value
1 Remote start Close to activate
2 Lamp test Close to activate
3 User configured Close to activate, Warning Active from safety on
4 User configured Close to activate, Shutdown Always active
5 User configured Close to activate, Shutdown Active from safety on
6 User configured Close to activate, Electrical trip Always active
