DSE Model 5220 Automatic Mains Failure & Instrumentation System Operators Manual
5220 OPERATING MANUAL ISSUE 5.1 18-Jun-07 AM 41
Output settings – Relay Value
1 Energise Preheat (during pre-heat timer)
2 Energise Common alarm
3 Energise System in auto mode
4 Energise Close generator
5 De-energise Close mains
Output settings – Expansion A Value
1 Energise Output not used
2 Energise Output not used
3 Energise Output not used
4 Energise Output not used
5 Energise Output not used
6 Energise Output not used
7 Energise Output not used
8 Energise Output not used
LCD indicator settings Value
1 Lit Digital input 1 active
2 Lit Digital input 2 active
3 Lit System in auto mode
4 Lit Common alarm
Timer settings Value
Mains transient delay
#
1s
Start delay
#
5s
Pre-heat
#
0s
Cranking time
#
10s
Crank rest time
#
10s
Smoke limit 0s
Smoke limit off 0s
Safety on delay
#
10s
Overspeed overshoot
#
2s
Warming up time
#
0s
Transfer time 0.7s
Breaker close pulse 0.5s
Breaker trip pulse 0.5s
Return delay
#
30s
Cooling time
#
30s
ETS solenoid hold
#
0s
Fail to stop delay 30s
Generator transient delay 1s
Battery low volts delay 1m
Battery high volts delay 1m
LCD page timer 5m
Mains (utility) settings – Voltage/frequency Trip Return
Under volts trip
#
180V AC 200V AC
Over volts trip
#
280V AC 260V AC
Under frequency trip
#
45Hz 48Hz
Over frequency trip
#
52Hz 55Hz
