DSE Model 5220 Automatic Mains Failure & Instrumentation System Operators Manual
5220 OPERATING MANUAL ISSUE 5.1 18-Jun-07 AM 47
15.3 5220 IDMT TRIPPING CURVES (TYPICAL)
5220 Delayed over-current protection
1
10
100
1000
10000
100000
1000000
123
Current as a multiple of the trip-point setting (tripping curve = 36)
Tripping time in seconds
