Installation precautions
Connect the LAN cable only to a computer LAN connection. Other similar connectors
may have a dangerously high voltage source.
The projector must be installed only by suitably qualied personnel, in accordance with
local building codes.
The projector should be installed as close to the power outlet as possible.
The power connection should be easily accessible, so that it can be disconnected in an
emergency.
Ensure that there is at least 50cm (19.7in) of space between the ventilation outlets and
any wall, and 30cm (11.8in) on all other sides.
Do not install the projector close to anything that might be affected by its operational
heat, for instance, polystyrene ceiling tiles, curtains etc.
Place the projector in a dry area away from sources of dust, moisture, steam, smoke,
sunlight or heat.
The projector is heavy. Use safe handling techniques when lifting the projector.
Do not drop or knock the projector.
Before installation, make sure that the surface, ceiling or rigging that is to support the
projector is capable of supporting the combined weight of the projector and lens.
When stacking projectors, the stack MUST be vertical, to ensure that the stresses are
distributed to all four chassis corners.
Do not stack more than 3 projectors.
Do not place heavy objects on top of the projector chassis. Only the chassis corners
and the optional rigging frame are capable of withstanding the weight of another
projector.
Backup safety chains or wires should always be used with ceiling mount installations.
The projector can be operated in any position. It is recommended to position the
projector in portrait mode with inputs facing upward, as shown in the diagram:
1
Recommended positions: inputs side up
2
Also possible
Pitch
360°
2
30°
330°
2
1
Roll
