Digital Projection E-Vision Laser 4K Series
Rev A June 2017
Page 5
Important Information
Electrical and physical specications
Main Voltage 100-240 VAC 50/60Hz (Switch selectable)
Operating Temperature 5°C to 40°C (41 F to 104 F)
Storage Temperature -10°C to 60°C (14 F to 140 F)
Operating Humidity 10% to 85% non-condensing
Dimensions: W 500 mm (19.7 in), H 218 mm (8.6 in), D 598 mm (23.5 in)
Weight 29 kg (63.9 lb) without lens
Power Consumption at 100 VAC: 920 W max
at 240 VAC: 880 W max
Standby power: < 6W (normal), <3W (ECO), <0.5W (PowerSAVE)
Thermal Dissipation at 100 VAC: 3139 BTU/Hour max
at 240 VAC: 3002 BTU/Hour max
Laser precautions
CLASS 3R LASER PRODUCT
This Laser Product is designated as Class 3R during all procedures of operation.
LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
Do not point laser or allow laser light to be directed or reected toward other people or
reective objects.
Direct or scattered light can be hazardous to eyes and skin.
There is a potential hazard of eye exposure to laser radiation if the included
instructions are not followed.
Caution – use of controls or adjustments or performance of procedures other than
those specied herein may result in hazardous radiation exposure.
Laser Parameters:
Wavelength 450nm - 460nm (Blue)
Mode of operation Pulsed, due to frame rate
Pulse width 0.74ms
Pulse repetition rate 240Hz
Maximum laser energy 0.376mJ
Total internal power 240Wmax
Apparent source size >10mm, at lens stop
Divergence >100 mili Radian
