11
Contact pins
A five pin connector on top of the PSU for
interacting with communication handles.
Status indicator
The status indicator diode on the front
provides the following feedback signals
about the state of the PSU:
• OFF - There is no power being fed to the
PSU.
• GREEN - In the case of being stacked-
PSU is on the top and controlling other
PSU in the stack.
• AMBER - PSU is controlled by another
PSU.
• RED blinking - There is an error. Informa-
tion will be displayed in the master PSU.
• GREEN or AMBER blinking - communica-
tion activity via DMX 512 or WiFi Art-Net.
DS6 User Manual
1. HARDWARE / PSU interface
