1. 1/4” Inst Input Jack
Connect a guitar, bass, or keyboard output here.
2. XLR Mic Input Jack
Plug your microphone in here. Accepts low impedance dynamic or self
powered condenser microphones.
3. 1/8” Aux Input Jack
Plug your CD or other music playback source in here. (Any stereo source is
summed to mono when recorded.)
4. 1/4” Output Jack
Connect this output to the input of a guitar amplifier, a channel of a mixer,
or headphones.
Guided Tour - Rear Panel
