DigiTech STUDIOQUAD User Manual

27
✓✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Octal Pitch Quad Pitch Stereo Dual Pitch Stereo Pitch
FX Lvl Controls the signal input level fed to the Module. Varies from OFF to 100%.
Dry: Lvl Controls the level of the dry (uneffected) signal. Ranges from OFF to 100%.
Balance Controls the left/right positioning of the dry signal in the stereo soundfield. Varies from -99 (all left) to
99 (all right).
✓✓✓
Dtn A - B
Controls the detuning amount for pitch-shifted voices A and B. As DTN moves away from zero,
dissonance becomes more pronounced. Low DTN settings (near zero) can be useful for thickening
or enhancing the imaging of the source material. Ranges from -50% to 50%.
✓✓✓
Shft A - B
SHFTA and SHFTB control the pitch intervals between the original note and voices A and B of the
pitch shifter. Pitch shifters can be used for a wide variety of effects, including doubling, octave
division, and chromatic harmonies. Each Pitch Shifter has a 4-octave range, stepped in semitones
from -24 to +24.
✓✓
Dtn C - D
See Detune A - B
✓✓
Shft C - D
See Shift A - B
✓
Dtn E - H
See Detune A - B
✓
Shft E - H
See Shift A - B
Out A - B
Adjusts the overall level of pitch-shifted voice A or B. Ranges from OFF to 100%.
Pan A - B
Controls the placement of pitch-shifted voice A or B in the stereo image. Varies from -99 (all left) to
99 (all right).
Out LA - LB
Adjusts the left side level of pitch-shifted voice A or B. Ranges from OFF to 100%.
Out RA - RB
Adjusts the right side level of pitch-shifted voice A or B. Ranges from OFF to 100%.
Spread
Controls the width of the effect's stereo imaging. The higher the setting, the wider the image.
The lower the setting, the more monophonic the effect becomes. Ranges from 1 to 10.
Pan C -D
Controls the stereo soundfield placement of pitch-shifted voice C or D. Varies from -99 (all left) to
99 (all right).
Out C - D Adjusts the overall level of pitch-shifted voice C or D. Ranges from OFF to 100%.
✓
Out E - H
Adjusts the overall level of pitch-shifted voices E through H. Ranges from OFF to 100%.
✓
Pan E - H
Controls the stereo soundfield placement of voices E through H. Varies from -99 (all left)
to 99 (all right).
PARAM. DESCRIPTION
Pitch Shifters
✓
✓
✓
✓
✓
Dual Pitch
✓
✓
✓
Out L - R
Adjusts the left or right output level of the pitch-shifted voice. Ranges from OFF to 100%.
✓
Dtn
See Detune A - B
✓
Shft
See Shift A - B
Section 3 - Effects and Parameters
Studio Quad Owner's Manual
