Digitrax Zephyr xtra - Cabling and System Clearing; Testing LocoNet Cables with LT1

©2012 Digitrax, Inc. www.digitrax.com 49
227;5/'31<;2'A<-<B? /F<BA
Layout Power
District
(Double Gapped)
Layout Power
District
(Double Gapped)
Adding A Second DCS51 To Your Layout
DCS51 running as the system's command station
Rail A
Rail B
Double Gaps
Between Layout
Power Districts
LocoNet Cable
Rail A
Rail B
LocoNet Cable
(With the original factory setting of Option Switch 02 set to "t")
DCS51 running as a booster and throttle
(Option Switch 02 set to "c")
$'
