6 www.dimplex.com
Fireplace Installation
WARNING: Ensure the power
cord is not installed so that it is
pinched or against a sharp edge
and ensure that the power cord is
stored or secured to avoid trip-
ping or snagging to reduce the
risk of re, electric shock or injury
to persons.
WARNING: Construction
and electrical outlet wiring must
comply with local building codes
and other applicable regulations
to reduce the risk of re, electric
shock and injury to persons.
WARNING: Do not attempt
to wire your own new outlets or
circuits. To reduce the risk of
re, electric shock or injury to
persons, always use a licensed
electrician.
WARNING: To reduce the risk
of re, do not store or use gaso-
Figure 1
27 ⅜”
(695 mm)
22 ⅞”
(580
mm)
23 ½”
(596 mm)
8 ¾”
(222 mm)
26 ¼”
(663 mm)
line or other ammable vapors or
liquids in the vicinity of the heater.
CAUTION: Clearance for air
circulation beneath the re-
place insert is provided by two
rubber feet.
Do not install the replace
insert directly on carpet or
similar surfaces which may
restrict air circulation.
CAUTION: If installing the
replace in a carpeted area, place
a one-piece, solid, at surface
under the replace. Ensure that
both of the feet rest securely on
this surface.
!
NOTE: The dimensions of the
replace with the trim are 27
⅜ in. (695 mm) wide x 23 ½ in.
(596 mm) high x 8 ¾ in. (222
mm) deep. Dimensions without
trim are 26 ¼ in. (663 mm)
