10 www.dimplex.com
Operation
WARNING: This electric
rebox must be properly installed
before it is used.
Manual Controls
The controls for the replace are
behind the access panel located
at the bottom of the replace
(Figure 5).
A. On/Off Switch
The On/Off Switch supplies power
to all replace functions.
B. Flame Action Control
Turn the ame action control knob
to adjust the ame speed to the
desired level.
C. Interior Light Control
Turn the interior light control
knob to increase or decrease the
brightness of the interior light.
D. Heater Thermostat Control
To adjust the temperature to your
B
Figure 5
CA D E
individual requirements, turn the
thermostat control clockwise all
the way to turn on the heater.
When the room reaches the
desired temperature, turn the
thermostat knob counter clock-
wise until you hear a click. Leave
in this position to maintain the
room temperature at its setting.
For additional heat, turn clockwise
until you hear the click again and
the heater will turn on. To turn the
heater off, rotate the knob fully
counter clockwise.
E. Heat On/Off Switch
Turns heat on or off.
!
NOTE: The heater on your
replace may emit a slight, harm-
less odor when rst used. This
odor is a normal condition caused
by the initial heating of internal
heater parts.
