13
11. Replace the Log Set by
inserting the front edge of the
replace and push down on
the rear edge of the Ember
Bed until it snaps into place
(Figure 7).
12. Lay unit on it’s back and slide
front glass back into position
and attach trim.
!
NOTE: Ensure the Log Set is
installed tightly under the back
ledge to prevent light leakage.
Upper Light Bulb Requirements
Quantity of two clear chandelier
or candelabra bulbs with an E-12
(small) socket base, 15 Watt
rating. Do not exceed 25 Watts
per bulb.
To access the upper light bulb
area:
CAUTION: Allow at least ve
minutes for the light bulbs to cool
before touching them to avoid
accidental burning of the skin.
1. Slide replace out of mantel.
2. Lay unit on it’s back for safe
removal of Front Glass.
3. Remove four Phillips screws
from right side of Trim.
4. Remove Trim.
5. Slide glass to the right side
of the replace to remove
(Figure 6).
6. Upper bulbs are located in
the upper left and upper right
corners of replace.
7. Unscrew bulbs counter
clockwise.
8. Insert new bulbs.
9. Lay unit on it’s back slide
front glass back into position
and attach Trim.
Glass Cleaning
The glass is cleaned in the factory
during the assembly operation.
During shipment, installation,
handling, etc., the clear door may
collect dust particles, these can
be removed by dusting lightly with
a clean dry cloth.
To remove ngerprints or other
marks, the clear door can be
cleaned with a damp cloth.
Fireplace Surface Cleaning
Use a cloth dampened with
warm water only to clean painted
surfaces of the electric replace.
Do not use abrasive cleaners.
Maintenance
