Dimplex BF8000ST Owner's Manual

7
Figure 3Figure 2
Foam
Block
Cable
Ties
Front
Glass
Trim
Track
wide x 22 ⅞ in. (580 mm) high
x 8 ¾ in. (222 mm) deep. The
replace does not require any
additional venting (Figure 1).
Fireplace Assembly
The only assembly required is
to slide the front glass onto the
replace and install hardware to
keep it in place.
1. Remove replace and glass
carefully from the carton,
discard the plastic bag and
foam packaging.
2. Remove the foam block from
within the replace (Figure 2).
3. Using side cutters or scissors,
cut and remove the two cable
ties as shown in Figure 1 and
Fireplace Installation
remove the cardboard that
protects the log set.
4. Remove the right hand side
trim by removing four Phillips
screws at the side of the
replace.
5. Place the Front Glass onto
the track of the replace
(Figure 3) and slide it along
the front until it reaches the
far left of the unit.
6. Re-attach the right hand trim
piece using the four Philips
screws from step 4.
Mantel Installation
Install the replace assembly
into the mantel (refer to mantel
assembly instructions).

Dimplex BF8000ST Specifications

General

Brand	Dimplex
Model	BF8000ST
Category	Indoor Fireplace
Language	English
