26 ¾”
(679 mm)
23 ⅛”
(587 mm)
9”
(229 mm)
Figure 4
Fireplace Installation
locate replace where it may
fall into a bathtub or other water
container. High temperatures
may be generated under certain
abnormal conditions. Do not
partially or fully cover or obstruct
the front of this heater.
M
BLOWER
MOTOR
CUT-OUT
THERMOSTAT
ELEMENTS
M
SPEED
CONTROL
HEATER ON-OFF
N
L
MAIN ON-OFF
FLICKER
MOTOR
DIMMER
UPPER
LIGHTS
LOWER
LIGHTS
Wiring
