Dimplex CAS1000 - Page 3

>210cm
2
Eg. 42cm x 5cm
>210cm
2
Eg. 14.5cm x 14.5cm
Dim A 300mm
Dim B
Min: 225mm
Max: 260mm
400mm
400mm
400mm
MODEL DIM ‘A’
CAS500 508mm
CAS1000 1017mm
Fig.1
Fig.2
FUEL BED DIM ‘B’
METAL 304mm
LOG 354mm
Fig. 3
