EN-32 452172.66.10-EN · FD 0311 www.dimplex.de
English LIA 0608BWCF M - LIA 1316BWCF M
for circulation pipe inches 3/4" external thread 3/4" external thread
unmixed heating circuit inches 1 1/4" external thread 1 1/4" external thread
Anode diameter mm 33 33
Anode length mm 690 690
Anode connection thread inches 1 1/4" internal thread 1 1/4" internal thread
7 Electrical connection
7.1 Supply voltage / fusing Outdoor unit 1~/N/PE 230 V (50 Hz) / C20A 1~/N/PE 230 V (50 Hz) / C20A
RCD type B B
7.2 Control voltage / fusing 1~/N/PE 230 V (50 Hz) / C13A 1~/N/PE 230 V (50 Hz) / C13A
7.3 Degree of protection according to EN 60 529 Indoors / outdoors IP 20 / IP X4 IP 20 / IP X4
7.4 Starting current limiter Inverter Inverter
7.5 Rotary field monitoring Yes Yes
7.6 Starting current A -- --
7.7 Nominal power consumption at A7/W35 / max. consumption
1
3
kW 1.24 / 3.22
6
2.00 / 3.91
6
7.8 Nominal current at A7/W35 / cos φ A 5.4 / 0.97 8.7 / 0.97
7.9 Nominal power consumption at A2/W35
1
kW
1.26 2.02
7.10 Power consumption of compressor protection (per compressor) W -- --
7.11 Power consumption of fan W 100 100
7.12 Supply voltage / fusing (∑ Pmax = 7.5 kW) indoor unit 1~/N/PE 230 V (50 Hz) / B35A 1~/N/PE 230 V (50 Hz) / B35A
3~/N/PE 400 V (50 Hz) / B20A 3~/N/PE 400 V (50 Hz) / B20A
8 Complies with the European safety regulations
See CE declaration of conformity See CE declaration of conformity
9 Additional model features
9.1 Type of defrosting Reverse circulation Reverse circulation
9.2 Condensate tray frost protection / Water in device is protected from freezing
7
Yes / Yes Yes / Yes
9.3 Max. operating overpressure (heat source/heat sink) bar 3.0 3.0
10 Heat output / cooling capacity /
coefficients of performance (COP)
10.1 Heat output / coefficient of performance (COP)
1
8
EN 14511 EN 14511
at A-15 / W35 kW / ---
9
4.00 / 2.34 6.34 / 2.46
at A-7 / W35 kW / ---
9
6.21 / 2.68 8.31 / 3.11
at A-7 / W55 kW / ---
9
5.22 / 1.96 7.05 / 1.97
at A2 / W35 kW / ---
9
5.50 / 3.95 8.20 / 4.05
at A7 / W35 kW / ---
9
6.20 / 5.00 10.00 / 5.00
at A7 / W45 kW / ---
9
6.35 / 3.75 10.00 / 3.80
at A7 / W55 kW / ---
9
6.90 / 2.91 9.72 / 3.04
at A10 / W35 kW / ---
9
7.35 / 5.02 10.00 / 5.13
at A20 / W35 kW / ---
9
6.98 / 5.91 10.70 / 6.72
at A20 / W55 kW / ---
9
6.81 / 3.60 9.85 / 3.88
10.2 Cooling capacity / COP
1
8
at A25 / W10 kW / ---
9
7.37 / 4.17 8.26 / 4.56
at A25 / W20 kW / ---
9
8.52 / 6.40 12.00 / 5.79
at A35 / W10 kW / ---
9
7.22 / 3.55 9.48 / 3.72
at A35 / W20 kW / ---
9
7.87 / 4.98 12.70 / 4.73
1. This data indicates the size and capacity of the system according to EN 14511. For an analysis of the economic and energy efficiency of the system, the bivalence point and
the regulation should be taken into consideration. These figures are only achieved with clean heat exchangers. Instructions for care, commissioning and operation can be found
in the relevant sections of the installation and operation instructions. The specified values have the following meaning, e.g. A7/W35: Heat source temperature 7 °C and heating
water flow temperature 35 °C.
2. The specified sound pressure level corresponds to the operating noise of the heat pump in heating operation at 35 °C flow temperature.
The specified sound pressure level is the free sound area level. The measured value can vary by up to 16 dB(A) depending on the installation location.
3. In reduced operation, the heat output and the COP are reduced.
4. Note that additional space is required for pipe connection, operation and maintenance.
5. Factory settings 6 KW
6. Max. intake incl. pipe heater (state of supply)
7. The heat circulating pump and the heat pump controller must always be ready for operation.
8. Indoor and outdoor unit must be connected with two refrigerant pipes (high and low pressure). The length information refers to one section. The specified technical data applies
to a refrigerant pipe length of 3-15 m per section. With a refrigerant pipe over a length of 15 metres, the heat output and the COP are reduced. The maximum permissible
section length (without adjusting the refrigerant quantity) is 15 m. The refrigerant quantity pre-filled at the factory is sufficient up to this length. From a single pipe length of
over 15 m, the refrigerant quantity must be adjusted. The maximum permissible pipe length with topping up of refrigerant is 30 m. The specified directives for routing refrig-
erant pipes and topping up refrigerant can be found in the installation and operating instructions.
9. You can find additional performance data in the installation and operating instructions.
