www.dimplex.de 452172.66.10-EN · FD 0311 EN-31
LIA 0608BWCF M - LIA 1316BWCF M English
13 Device information
1 Type and order code
LIA 0608BWCF M LIA 0911BWCF M
2 Design
Heat source Air Air
2.1 Version Universal with hydrotower Universal with hydrotower
2.2 Controller WPM Touch WPM Touch
2.3 Thermal energy metering Yes Yes
2.4 Installation location Indoors/outdoors Indoors/outdoors
2.5 Performance level Variable Variable
3 Operating limits
3.1 Heating water flow/return ° C up to 65 / from 12 up to 65 / from 12
3.2 Air (heating) ° C -25 to +35 -25 to +35
3.3 Cooling water flow ° C 7 to 25 7 to 25
3.4 Air (cooling) ° C -5 to +43 -5 to +43
4Flow
1
/ sound
4.1 Heating water flow heat pump circuit / free compression
Nominal flow in accordance with EN 14511
at A7 / W35...30 m³/h / Pa
1.07 / 8603 1.72 / 22533
at A7 / W45...40 m³/h / Pa 1.10 / 8898 1.72 / 22129
at A7 / W55...50 m³/h / Pa 1.04 / 7741 1.65 / 20082
Minimum heating water flow rate see Heat pump circuit m³/h/Pa 0.65 / 71900 1.07 / 63800
4.2 Cooling water flow rate heat pump circuit / free compression
Nominal flow according to EN 14511
A35 / W18...23 m³/h/Pa
1.07 / 10900 1.72 / 26300
Minimum cooling water flow rate m³/h/Pa 1.07 / 10900 1.72 / 26300
4.3 Sound power level according to EN 12102 outdoors at A7/W55
Normal operation / reduced operation (outdoors) dB(A)
58 60
4.4 Sound pressure level at 10 m distance
2
3
normal operation/reduced operation dB(A)
30 / 25 32 / 27
4.5 Air flow, normal operation / reduced operation m³/h 2770 / 2030 4030 / 2910
4.6 Noise-power level in accordance with EN 12102
indoors A7/ W55 dB(A)
42 42
4.7 Sound pressure level at a distance of 1 m, indoors
2
dB(A)
35 35
5 Technical data
5.1 Buffer tank
Nominal volume Litres 100 100
Max. permissible operating temperature °C 85 85
Max. permissible operating pressure bar 2.0 2.0
Immersion heater (optional) kW up to 6 up to 6
5.2 Domestic hot water cylinder
Nominal volume Litres 277 277
Heat exchanger area m² 3.15 3.15
Max. permissible operating temperature °C 95 95
Max. permissible operating pressure bar 10.0 10.0
Immersion heater kW 1.5 1.5
5.3 Start-to-leak pressure, safety valve bar 3.0 3.0
6 Dimensions, weight and filling quantities
6.1 Device dimensions
4
indoor unit H x W x D mm
outdoor unit H x W x D mm
1920 x 733 x 959
712 x 1008 x 426
1920 x 733 x 959
865 x 1118 x 523
6.2 Weight outdoor unit / incl. packing kg 60 / 65.5 78.5 / 92
6.3 Weight indoor unit / incl. packing kg 210 / 213 210 / 213
6.4 Refrigerant/total filling weight Type / kg R32 / 1.5 R32 / 1.65
6.5 GWP value / CO
2
equivalent --- / t
657 / 1.01 657 / 1.2
6.6 Lubricant / total filling quantity Type FW68S / 0.46 FW68S / 0.46
6.7 Volume of heating water in the outdoor unit Litres 0 0
6.8 Electrical pipe heater kW
2, 4 or 6
5
2, 4 or 6
5
6.9 Tilted dimension indoor unit mm 2000 2000
6.10 Device connections indoor unit
for domestic hot water inches 1" external thread 1" external thread
