LIA 0608BWCF M - LIA 1316BWCF M English
CN26
Communication connection for power meter
CN27
Connection for 2-way valve 6
CN28
Communication connection for XYE
CN29
Connection for low pressure switch and quick check
CN30
Connection for fan 15 VDC power supply
CN31
Connection for low pressure switch
CN32
CN33
CN34
CN35
Connection for temperature sensor (TW_out, TW_in;T1, T2,
T2B)
CN36
Communication connection for PCB A
CN37
Communication connection for H1H2E
CN38
Connection for earthing wire
CN41
Power supply connection for PCB C
CN53
Connection for fan 310 VDC power supply
CN109
Connection for fan
