11
M
120V / 12V
~
AC / DC
+T°
M
+T°
FLAME LIGHTS
6 x 0.20mA LEDs
L
REMOTE
3 x 1W LEDs
360 LIGHTS
FLICKER
ASH MAT ASSEMBLY
MOTOR
CONTROL BOARD
IR EYE/KEY BOARD
N
CUTOUT
4-7 x 0.20mA LED STRIP
2 PIECES
RLG20BR, RLG20FC
120V / 12V
~
AC / DC
+T°
M
M
+T°
BLOWER
MOTOR
4 x 1W LEDs
360° LIGHTS
CONTROL BOARD
FLAME LIGHTS
REMOTE
N
IR EYE/KEY BOARD
L
6 x 0.20mA LEDs
4-7 x 0.20mA LED STRIP
2 PIECES
CUTOUT
FLICKER
MOTOR
ASH MAT ASSEMBLY
RLG25BR, RLG25FC
