OPERATOR’S MANUAL with Maintenance Information
Schematic
57
Hydraulic Schematic
Lift Cylinder
Flat overload（Option）
1.5mm
1.0mm
1.0mm
Overflow
110bar
Overflow
155bar
Motor
Filter
Tank
C
B
A
Steer Cylinder
Pump unit
Lower valve
