DINGLI S036-RS User Manual

OPERATOR’S MANUAL with Maintenance Information
Control Panel
12
S036-RS
Height, working maximum
5.6 m
Height, platform maximum
3.6 m
Height, stowed maximum
Rails up
2.02 m
Height, stowed maximum
Rails folded
1.66 m
Width
0.76 m
Length, platform retracted
1.44 m
Length, platform extended
2.04 m
Platform dimensions
Platform length × width
1.29×0.7 m
Platform extension length
0.6 m
Maximum load capacity
240 kg
Maximum wind speed
12.5 m/s
Wheelbase
1.05 m
Turning radius (outside)
1.55 m
Turning radius (inside)
0.4 m
Ground clearance
6 cm
Ground clearance
Pothole guards deployed
1.5cm
Weight
（See Serial Label）
Machine weights vary with option configurations
Power source
2 Batteries , 12V 85Ah
Controls
Proportional
AC outlet in platform
Standard
Maximum hydraulic pressure
(functions)
155 bar
System voltage
24 V
Tire size
Φ230×80 mm
Airborne noise emissions
<70 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m/s
2
Maximum slope rating,
Stowed position
25%
Maximum side slope rating,
Stowed position
25%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope
X-1.5°,Y-3°
Drive speeds
Stowed, maximum
4.0 km/h
Platform raised, maximum
0.5 km/h
Floor loading information
Tire load, maximum
450 kg
Tire contact pressure
8 kg/cm
2
784 kPa
Occupied floor pressure
1138 kg/m
2
11.2 kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation

DINGLI S036-RS Specifications

General

Brand	DINGLI
Model	S036-RS
Category	Scissor Lifts
Language	English
