Dingo 950 Operation & Maintenance Manual
19
Attachments
Connecting
IMPORTANT: Use only Dingo approved attachments. Attachments can change
stability and operating characteristics of the machine. The warranty of the machine
may by voided if used with unapproved attachments.
IMPORTANT: Before connecting any attachments to the machine, make sure mount
plates are free of any dirt and debris.
1. Move pump control lever to slow (turtle) position.
2. Slowly push the attachment tilt lever forward to tilt the attachment mount
plate forward.
3. Position mount plate into the upper lip of the attachment’s receiver plate.
4. Raise the loader arms while tilting back the mount plate at the same time.
5. IMPORTANT: The attachment should be raised enough to clear the ground
and the mount plate tilted all the way back.
6. Turn the ignition key to “OFF” to stop the engine.
7. Engage the attachment lock pins (the lock pins should go down 15mm as
they turn).
Note: Lock pins are located on the operator side of the mount plate and
should be turned toward the inside to engage.
8. Note: Proceed to next step if auxiliary hydraulics are required with
attachment.
9. IMPORTANT: Make sure all foreign matter is cleaned from hydraulic
connections before making connections.
10. Move the auxiliary hydraulics lever to the forward, backward, and back to
neutral position to relieve hydraulic pressure at the hydraulic couplers.
11. Remove protective covers from the hydraulic couplers on machine. Connect
covers together to prevent contamination during operation.
12. Slide collar back on hydraulic coupler and connect attachment couplers to
machine couplers. There will be two connections to make.
13. Confirm that connection is secure by pulling on the hoses.
Disconnecting
1. Lower attachment to the ground or onto a trailer.
2. Turn the ignition key “OFF” to stop the engine.
3. Move the auxiliary hydraulics lever forward, backward and back to neutral
position to relieve hydraulic pressure at the hydraulic couplers.
4. Slide collar back on the hydraulic coupler and disconnect attachment
couplers from machine couplers. (Note: if this is difficult return to step 3 and
repeat.)
5. IMPORTANT: Connect attachment hoses together to prevent contamination
during storage.
6. Install protective covers onto machines hydraulic couplers.
7. Disengage the attachment lock pins by turning them to the outside.
