Dingo 950 Operation & Maintenance Manual
9
SPECIFICATIONS
General Specifications
(without operator and without attachments)
All Dingo 950 models have the same outside dimensions/Chassis.
(Approximate Only)
Overall width 840mm-1050mm
Overall length (without attachment) 1565mm
Overall height 1200mm
Maximum Operating Height (with standard bucket) 2080mm
Operating Weight 700-800kg
Turning radius with standard bucket 1300mm
Rated lift capacity - bucket (with 90kg operator) 250kg
(lifting capacity up to 500 kg with certain attachments)
Speed 0→6 km/hr
Angle of departure 20°
Engine HP 20-22 HP
Wheel motor sizes 29 cu in
Wheel base 710-800mm
Drive Chain ASA 60H (Heavy Link ¾”)
Ground clearance 135mm
Tyre size 18 x 8.50 x 8 (4 ply) std
Hydraulics 2 pump
Pump sizes 9 & 3 cc
System relief pressure (hydraulic) 3000psi (206 Bar)
Hydraulic Reservoir capacity 60 litres
Hydraulic Output 43 litres per minute
Filtration 25 micron
Standard bucket capacity 0.11 cu m
Standard bucket dump height 1240mm
Reach fully raised standard bucket 600 mm
4 in 1 bucket capacity 0.11 cu m
4 in 1 bucket dump height 1750mm
Reach fully raised 4 in 1 bucket 600 mm
Chipbark bucket capacity 0.18 cu m
Height to hinge pin (std bkt in highest position) 1680mm
Specifications and design subject to change without notice.
