Description
USER_MAN_ENG_MCWN
Main components
The machine is made up of the following main components:
Pos. Component
1
LOAD CELL BODY
2
SHACKLE FOR CONNECTION BETWEEN THE LIFTING EQUIPMENT HOOK AND THE LOADING CELL
3
SHACKLE FOR THE CONNECTION BETWEEN THE LOAD CELL AND THE LOAD GRIPPING DEVICES
4
ELECTRONIC EQUIPMENT TO CONVERT THE SIGNAL COMING FROM THE TRANSDUCER IN A WEIGHT UNIT, WITH
MEASURING DISPLAY AND ADJUSTMENT SYSTEMS
5
RJ11 STANDARD CONNECTOR FOR RS232 SERIAL CONNECTION TO ANY EXTERNAL DEVICES.
