Safety devices
USER_MAN_ENG_TPW_v4
Safety pictograms applied to the machine
Stickers and safety plates are applied to the machine, as shown in the following table. Refer to the image for positioning.
Pos. Pictogram Description
1
Mod.
Sn
TPWLKP-5
0100574294
Dini Argeo - v. Fisica, 20 - 41042 Fiorano (MO) Italy
UK 2945
6V DC
Max
Min
e =
B1W1 B1W2 B1W3
500 kg 1000 kg 2000 kg
4 kg 10 kg 20 kg
0.2 kg
0.5 kg
1 kg
CE IDENTIFICATION PLATES
2
WARNING PLATE:
• load lowering;
• load transport;
• load lifting;
• oil filling;
• do not use on slopes.
3
MANUFACTURER DATA STICKER
4
BATTERY INDICATIONS STICKER
