TPW
44
x 5
Use
USER_MAN_ENG_TPW_v4
IMPORTANT!
With approved scale, you can perform weighing on EUR pallet 800 x 1200 mm
(UIC standards 435-2 and UIC 435-4 ref.).
Load lifting and weight reading
Lift the load, as shown in the figure below.
The value of the weighing can be read on the display.
Weighing accuracy is achieved when the pallet truck is fully stationary.
WARNING!
Make sure the pallet is fully raised from the ground.
Pallet truck positioning
Position the pallet truck under the load to be weighed, as shown in the figure below.
