TPW
28
Packaging and handling
USER_MAN_ENG_TPW_v4
Packaging
The pallet truck is transported disassembled and packaged inside a cardboard box with a strapped pallet. The
TPWLKI and TPWLKW models on the other hand, are transported fully assembled on a pallet and strapped to it.
Upon receiving the packaged machine, the customer must verify that there is no damage caused by the mode of
transport or by the personnel in charge of the specific operations.
If damage is detected, leave the packaging in question in the state found and immediately request the assessment of
the damage by the competent shipping company, then communicate the damage found to the competent transport
insurance and sales outlet by means of a damage certificate.
Packaging handling
The packaging must be moved by means of a forklift with a capacity suitable for the weight to be lifted (refer to the
table below to check the weight of your model).
Weights with transport crate:
MODEL WEIGHT
TPWN 124 kg
TPWLK 138 kg
TPWA 138 kg
TPWP 138 kg
TPWLKW 148 kg
TPWLKI 135 kg
TPWI 135 kg
For handling, proceed as follows:
1. Position the forklift forks under the packaging containing the machine, as shown in the figure.
2. Make sure the forks come out from the rear of the load, for a length sucient to eliminate any risk of tipping.
3. Lift slowly, making sure that the centre of gravity of the section is positioned at the centre of the lifting forks.
POSITIONING
FORKS
