TPW
78
A B C
D E
Maintenance
USER_MAN_ENG_TPW_v4
Oil level top-up
Tank top-up for models with pump with plug
Check the oil level every 6 months.
Only use hydraulic oil (not motor or brake oil) to top-up.
Oil viscosity: 30 CST at 40°C
Total volume: 0.3 l
A. Fully lower the forks.
B. Remove the protective casing, the seal and the cap.
C. If required, add up to 20 mm from the top edge of the tank.
D. Operate the pump several times to release any air from the
hydraulic circuit, then lower the forks completely.
E. Put the cap, the seal and the protective casing back on.
