3
© 2011 Directed Electronics. All rights reserved.
H1/10 BROWN (+) Siren Output
H1/11 RED (+)12 V Constant Power Input
H1/12 RED/WHITE (-) 200 mA Channel 2 Validity Output
Door Lock, 3-Pin Connector (H2)
1 GREEN (-) Lock, (+) unlock output
2 OPEN except if using 451M
3 BLUE (+) Lock, (-) unlock output
This security system can control two common power door lock types without
any additional parts. With certain vehicles, or if an actuator is to be installed,
either a 451M Door Lock Relay Satellite or two relays will be required.
Important:
For additional Door Lock information refer to Tech tip #1041 at
www.directechs.com or contact your local distributor.
Horn Honk, 3-pin connector
H/1
OPEN NO FUNCTION
H/2
BROWN/BLACK (-) 200 mA HORN HONK OUTPUT
H/3
OPEN NO FUNCTION
This wire outputs a single pulse when arming the system and two puls-
es when disarming the system. This wire will also output pulses for 30
seconds when the system is triggered or if panic mode is activated. If
the vehicle has a (+) horn circuit, a standard automotive SPDT relay or
a relay assembly package (p/n 8617) must be used.
