Directed Directechs DB3 User Manual

12
403.VW08 1.35 2020 Audi Q7 (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White No Connection No Connection
H2/2 Green/Black (-) PTS Output Rear of Center Console, black 17 pin plug, pin 1
Rear of Center Console, black 17 pin plug, pin 2
Rear of Center Console, black 17 pin plug, pin 3
Must use three 1A diodes.
Comfort System Module in left rear quarter panel, below fuse box,
blue-white 32 pin plug, pin 25
Comfort System Module in left rear quarter panel, below fuse box,
blue-white 32 pin plug, pin 26
Comfort System Module in left rear quarter panel, below fuse box,
blue-white 32 pin plug, pin 10
-
-
-
-
-
-
Yellow/Gray (PTS 1
alternate)
White/Gray (PTS 2
alternate)
Blue/Yellow (PTS 3
alternate)
Yellow/Gray
White/Gray
Blue/Yellow
H2/3 Green/White No Connection No Connection
H2/4 Red/Black (-) Trunk Output No Connection
H2/5 Violet/White No Connection No Connection
H2/6 Gray (+) Brake Output [2] Driver Firewall, harness to engine compartment
Important! There are two possible connections, make sure to follow
the installation diagram.
Comfort System Module in left rear quarter panel, below fuse box,
black-white 32 pin plug, pin 12
+
+
Black/Red (alternate
location)
Black/Red
H2/7 Gray/Black No Connection No Connection
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown No Connection No Connection
H2/10 Yellow/Black No Connection No Connection
H2/11 Orange/Black No Connection No Connection
H2/12 Blue/Red No Connection No Connection
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green No Connection No Connection
H3/2 Blue No Connection No Connection
H3/3 Red/White No Connection No Connection
H3/4 White/Violet No Connection No Connection
H3/5 Violet/Black No Connection No Connection
H3/6 White/Black (-) Hood Switch Input
H3/7 Pink/White No Connection No Connection
H3/8 Violet No Connection No Connection
H3/9 Pink No Connection No Connection
H3/10 Blue/White No Connection No Connection
