14
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Flex 2011-2012
RX Yellow/Orange 4 Data (PATS) connector. Black 4 A
TX Violet/Gray 3 Data (PATS) connector. Black 4 A
12V Blue/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
Keysense Blue/Gray 5 (+) Ignition switch. Black 7 B
Parking Lights Violet/White 6 (+) SJB (Smart Junction Box) under drivers
dash.
Gray 13 H
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut SJB under drivers dash. Gray 26 G
Lock Blue/Green 17 (-) SJB under drivers dash. Gray 26 G
Unlock Yellow/Violet 4 (-) SJB under drivers dash. Gray 26 G
Power Liftgate Gray/Yellow N/A (-) Drivers kick panel harness to rear. N/A N/A K
Tach Green/Blue, Gray/Yellow,
Violet/Gray, Yellow/
Orange, Brown, Green/
White, Gray/Brown or
Violet/Orange
1 (AC) Any fuel injector. Gray 2 N/A
Ford Flex 2013-2016
RX Violet 4 Data (PATS) connector. Black 4 A
TX Yellow 3 Data (PATS) connector. Black 4 A
Power Liftgate Gray 6 (-) Power liftgate switch. Brown 6 F
12V Yellow/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet 6 (+) Ignition switch. Black 7 B
Keysense Blue 5 (+) Ignition switch. Black 7 B
Parking Lights Yellow/Blue 6 (+) BCM (Body Control Module) under drivers
dash.
Gray 10 H
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Violet 9 Cut BCM under drivers dash. Black 26 G
Lock Blue 6 (-) BCM under drivers dash. Black 26 G
Unlock Yellow 8 (-) BCM under drivers dash. Black 26 G
Tach Green/Blue, Gray/Yellow,
Violet/Gray, Yellow/
Orange, Brown, Green/
White, Gray/Brown or
Violet/Orange
1 (AC) Any fuel injector. Gray 2 N/A
