4
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Introduction
The FORD6 firmware for DS4+ is compatible with specific Ford and Lincoln vehicles. It is a complete solution for
remote start, security (when security features are enabled), bypass, and features built in Bluetooth 4.0 allowing
you to configure and control your system. This guide provides information on the installation of the module using
FORD6. Please refer to the DirectLink application or www.directechs.com for more information about which
configuration is best for your application.
Warning! This module is designed to be configured using the DirectLink application for mobile devices, however it can also
be configured using the web tool located at www.directechs.com. To download the DirectLink mobile application, please visit the
Google Play or Apple store.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
THFON1
Keys required for
programming
2
Keys required for
operation
0
The optional Plug & Play THFON1 T-Harness is sold separately.
Key2GO is required if only one key is available. You can program the interface without the need for Key2GO if two keys
are present.
Keys required to program:
80-Bit Encryption transponder: Requires two (2) keys for programming. Key2GO is NOT compatible.
40-Bit Encryption transponder: Programming can be completed with two (2) keys or with one (1) key if using Key2GO.
(See "Understanding the difference between a Ford 80 & 40 bit" on page 51 for more information)
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
It is important to check that the fuses are positioned correctly in the module. Refer to the "Fuse selection" section following
each installation type for more information.
Refer to the "Vehicle wiring reference chart" following each installation type.
General notes: This section highlights important information for this specific firmware.
[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.
[2] The siren is ONLY required when enabling the security features during module flashing.
[3] The green wire is ONLY required for starter disable and antigrind applications.
[4] Vehicles with install Type 3, 4, 6, 7 & 10 are NOT compatible with optional T-harness THFON1.
[5] Connections ONLY required if features do not operate in data.
[6] ONLY required if OEM alarm equipped.
Additional parts required (maximum required):
1 x 1A Diodes
86 85
30
87a
87
1 x Relay
0 x Resistor
0 x Fuse
