Dirt Devil fusion - 1.3 Inside the appliance

32
1 Overview
1.3 Inside the appliance
1 Housing cover
2 Dirt bin cover
3 Filter
4 Dirt bin
5 Handle for removing the dirt bin
6 Battery pack
7 Battery compartment
8 Dirt bin compartment
9 Appliance charging contacts
2
3
4
5
7
6
1
8
9
3
