11
Table 3-7, 48-48-5120 / 48-48-5120-H DC Capacity Values for Sample Battery Module
Systems
Parallel System Peak Current
Max Continuous
Discharge
Max Continuous
Charge
Usable Capacity
1 battery module 220 A 10 0 A 100 A 5,120 Wh
2 battery module 440 A 200 A 200 A 10,240 Wh
3 battery module 660 A 300 A 300 A 15,360 Wh
4 battery module 880 A 400 A 400 A 20,480 Wh
5 battery module 110 0 A 500 A 500 A 25,600 Wh
6 battery module 1320 A 600 A 600 A 30,720 Wh
3.7 Regulatory
Table 3-8, 48-48-5120 / 48-48-5120-H Regulatory
Regulatory
UN38.3 Transportation
IEC62619 (pending)
UL1973 (pending)
UL9540A (pending)
UL9540 (pending)
CE (pending)
4. TRANSPORTATION
Transport it in the original package or equivalent if the battery module is not
installed in equipment. Per the UN Handbook of Tests and Criteria, battery modules
are tested to part III, subsection 38.3 (ST/SG/AC.10/11/ Rev. 5). For transportation, the
battery modules belong to category UN3480, Class 9.
5. HANDLING
Before handling:
• Keep the battery module away from sparks and flames
• Disconnect the cables from the battery module
• Protect battery module terminals from short-circuiting and touch
• Do not lift or carry the battery module while it is in use or in operation
• Do not lift the battery module by attached battery cables
• Set the battery module Breaker in the OFF (Open) position
