Distinction PASRW030-BP2 - Imensions for Swimming Pool Heat Pump Unit

4
Unit: mm/inches
1.5’’
1.5’’
Water outlet
815/32.1’’
1115/43.9’’
Water inlet
182/7.2’’ 118/4.6’’
’’1.91/584
’’3.43/
078
1165/45.9’’
101/4.0’’
’’7.51/004
2. SPECIFICATION
2.2 Dimensions for Swimming pool heat pump unit
MODEL : PASRW030-BP2
Unit : mm/inches
MODEL : PASRW040/050-BP2
Unit : mm/inches
1002/39.4’’
770/30.3’’
1048.5/41.3’’
441.5/17.4’’
610/24.0’’
202/8.0’’
190/7.5’’
104/4.1’’
350/13.8’’
Water outlet
1.5’’
1.5’’
Water inlet
