3. INSTALLATION AND CONNECTION
3.5 Swimming pool heat pump electrical wiring
NOTE : Although the unit heat exchanger is electrically isolated from the rest of the unit, it simply prevents the
of electricity to or from the pool r. Grounding the unit is still required to protect you against short circuits inside
the unit. Bonding is also required.
The unit has a separate molded-in junction box a standard electrical conduit nipple already
in place. Just remove the on the front panel, feed your supply lines in through the conduit
nipple and the electric supply to the three connections already in the junction box
(four connections if three phase). To complete electrical hook up, connect heat pump by elec-
trical conduit, UF cable or other suitable means as (as permitted by local electrical au-
thorities) to a dedicated AC supply branch circuit equipped the proper circuit breaker,
disconnect, or time delay fuse protection.
Disconnect
A disconnect means (circuit breaker, fused or un-fused should be located sight of
and readily accessible from the unit, This is common practice on commercial and residential air
conditioners and heat pumps. It prevents remotely-energizing unattended equipment and permits
3.6 Initial startup of the unit
NOTE- In order for the unit to heat the pool or spa, the pump must be running to circulate through the
heat exchanger.
Start up procedure
1- T
2- Turn on the electrical supply to the unit, then press the key ON/OFF of controller, It should start in
several seconds.
3-
4- Wy.
the unit and pool pump to run 24 hours per day until desired pool temperature is reached. When
the unit off. The unit
automatically restart (as long
Time Delay
The unit is equipped a 3 minute built-in solid state restart delay included to protect control
circuit components and to eliminate restart cycling and contactor chatter. This time delay au-
tomatically restart the unit approximately 3 minutes after each control circuit interruption. Even
a brief interruption activate the solid state 3 minute restart delay and prevent the unit
from starting until the minute is completed. interruptions during the delay
