6. APPENDIX
No. Code Name Specifications Qty
1 HPX20000-110433 Compressor 5RD198ZAA21 1
2 HPX80701976 Chassis assembly Gray RAL403C 1
3 HPX80900298 Front box ABS gray RAL403C 1
4 HPX72200035 CM403 82300004+302020-00000027 1
5 HPX20000-220333 Remote control waterproof box ABS 1
6 HPX20000-220369 Fan net ABS matte black O500 1
7 HPX20000-270004 Axial fan blade Z500-145 1
8 HPX20000-330132 DC ZWS75-A 1
9 HPX80701977 Black network Galvanized sheet 1.0 gray RAL403C 1
10 HPX32009-120089 Finned heat exchanger 714x353x800x07x1.5 2.0 1
11 HPX32009-210663 Support plate Galvanized sheet 1.5 black 9005 1
12 HPX32009-220111 Top Cover ABS black fine lines 1
13 HPX32009-210662 Motor backet assembly Black 9005 1
14 HPX32008-210167 Condenser splint Galvanized sheet 1.5 black 9005 1
15 HPX32009-210658 Electrical cover Galvanized sheet 1.5 black 9005 1
16 HPX32009-120088 Titanium tube heat exchanger O12.7x10mO160thread 1
17 HPX80701978 Right side panel Galvanized sheet 1.5 black 9005 1
18 HPX32009-220029 Junction box B ABS Black 1
19 HPX32009-210664 Middle partition Galvanised sheet 1.0 black 9005 1
20 HPX2000-1460 Three links O6.5xO6.5(T)x0.75 T2M 1
21 HPX20000-140150 Needle valve 40mm 1/2’’ T0305-10 1
22 HPX20000-140573 Electronic expansion valve DPF(B)2.2C-105 1
23 HPX20000-360157 Pressure Switch 0.30MPa/0.15MPa±0.05 normally open 1
24 HPX2001-3605 Pressure Switch 3.2MPa/4.4MPa±0.15 normally closed 1
25 HPX20000-360059 Pressure Switch 3.2MPa/4.0MPa±0.15 normally closed 1
26 HPX2004-1444 Filter (R410A) O9.7-O9.7(O28) T2Y2 1
27 HPX20000-140618 Filter (R410A) O9.7-O6.5(O28) T2Y2 1
28 HPX20000-360005 Flow switch PSL-1 3/4 1
29 HPX20000-140485 Four way valve DSF-11E-R410A 1
30 HPX32009-210651 Electrical box assembly Black 9005 1
31 HPX20000-310170 Variable frequency drive SA.FNB75GW.1 1
32 HPX95005-310569 PC1002 Controller 20000-430177+35005-310569 1
