Cx Series Operator’s Manual Specifications - 105
C12x
Operation US Metric
Vehicle speeds
Max transit forward 120fpm 36.6m/min
Max transit reverse 120fpm 36.6m/min
Digging chain speed
35K 253fpm 77m/min
Spoils handling, single, open-end auger
Outer diameter 17” 432mm
Max operating weight 1360lb 617kg
Engine US Metric
Engine: Honda® iGX390
Fuel Gasoline
Cooling medium Air
Number of cylinders 1
Displacement
27.3in
3
389cm³
Bore 3.5” 88mm
Stroke 2.5” 64mm
Manufacturer’s net power rating @3600rpm (per SAE J1940) 11.7hp 8.7kW
Rated speed 3600rpm 3600rpm
Fuel consumption 0.92gph 3.5L/h
Max tilt angle* 20° 20°
* Exceeding these operational angles will cause engine damage. This DOES NOT IMPLY machine is stable to maximum angle of
safe engine operation.
