XT855 Operator’s Manual Controls - 25
Front Console
CMW
10. Hydraulic oil
temperature alarm
Sounds when hydraulic oil
temperature is above 210°F
(100°C).
• Allow unit to cool.
• Check hydraulic oil level.
11. Fuel gauge Displays fuel level in tank. Use no. 2 diesel fuel. See page 80 for
specific fuel recommendations.
Tank holds 10 gal (38 L).
12. Throttle To increase engine speed,
push.
To decrease engine speed,
pull.
Increasing engine speed also
increases attachment speed.
13. Auxiliary power outlet To operate work lights or
other 12V devices, plug into
outlet.
Item Description Notes
c00ic232h.eps
c00ic179h.eps
