Service - 92 XT855 Operator’s Manual
As Needed
CMW
As Needed
Adjust Track Tension
Adjust track tension as needed. To increase
tension, turn screw (1) clockwise. To reduce
tension, turn screw counterclockwise. When
tracks are properly tensioned, spring length (A)
should be 9 1/2” (241 mm).
Location Task Notes
TRACKS Adjust track tension
OPERATOR
STATION
Empty radiator cleanout
ENGINE
COMPARTMENT
Adjust fan belt
Adjust pump drive belt use belt tension meter, p/n 499-938
