XT855 Operator’s Manual Service - 93
As Needed
CMW
Empty Radiator Cleanout
Empty radiator cleanout as needed.
1. Remove radiator screen and the radiator
cover holding the screen in place.
2. Remove plate (shown) under unit.
3. Clean out all debris from cleanout area.
4. Replace plate, radiator cover, and radiator
screen.
Adjust Fan Belt
Adjust fan belt as needed.
1. Turn off engine and remove key.
2. Apply moderate thumb pressure to belt
between pulleys where shown.
3. Belt is properly tensioned when deflection is
about 1/4-3/8” (7-9 mm).
4. If needed, loosen alternator bolts (shown)
and pull alternator out until correct tension is
reached.
