Specifications - 98 XT855 Operator’s Manual
CMW
Performance U.S. Metric
Ground drive speed, forward 4.2 mph 6.8 km/h
Ground drive speed, reverse 4.2 mph 6.8 km/h
Ground pressure 4.0 psi 0.28 bar
Angle of departure 30° 30°
Tipping capacity 2500 lb 1134 kg
Rated operating capacity @ 35% of tipping capacity
Rated operating capacity was determined using a standard bucket in the drive position
with a center of gravity ____ in ( mm) from the face plate. Depending on the attachment,
the actual operating capacity of the attachment may vary.
950 lb 431 kg
Drawbar pull 2500 lb 11.1 kN
Hydraulic System U.S. Metric
Auxiliary: dual gear pumps
Flow rate 7/15 gpm 26.4/56.8
L/min
Pressure 3000 psi 207 bar
Ground drive: dual hydrostat
Flow rate 13 gpm 49.2 L/min
Pressure 3625 psi 250 bar
