XT855 Operator’s Manual Specifications - 99
CMW
Power U.S. Metric
Engine: Kubota D1105-T-E3B diesel (EPA Tier 4i, EU stage IIIA)
Cooling medium: coolant (see “Approved Coolant” on page 80.)
Number of cylinders: 3
Injection: indirect
Displacement
68.53 in
3
1123 cm
3
Bore 3.07 in 78 mm
Stroke 3.09 in 78.5 mm
* Maximum continuous tilt angle, fore and aft 20° 20°
* Maximum continuous tilt angle, side 20° 20°
Rated speed 3000 rpm 3000 rpm
Estimated net power per SAE J1349 (@ 3000 rpm) 29.5 hp 22 kW
Gross power per SAE J1995 32.8 hp 24.4 kW
* Exceeding these operating angles will cause engine damage. This DOES NOT IMPLY machine is stable to maximum angle of
safe engine operation.
Fluid Capacities U.S. Metric
Fuel tank 10 gal 38 L
Engine oil, with filter 4.2 qt 4 L
Hydraulic system 10 gal 38 L
